Introduce
The 5.12kWh wall-mounted home energy storage battery is a reliable and efficient energy solution for residential and light commercial users. It uses lithium iron phosphate (LiFePO4) batteries and can integrate solar and grid power. With a cycle life exceeding 6000 cycles at 80% depth of discharge and a service life exceeding 15 years, it ensures durability and cost-effectiveness. This product has obtained CE, UN38.3, and MSDS certifications, meeting global safety standards.
Features
Integrates solar and grid power for a reliable energy supply
Supports high-power charging and discharging.
Cycles over 6000 times at 80% DOD, with a lifespan exceeding 15 years.
Includes integrated inverter, system controller, advanced BMS technology, Wi-Fi, and control applications for remote monitoring and management.
Certified by CE, UN38.3, MSDS, and 3C, and constructed entirely of copper for enhanced safety. The system undergoes rigorous testing before delivery.
Application
This system is ideal for residential, small business, and light commercial applications that require reliable and scalable energy storage, especially for solar power systems.
Parameters
| Property | Value |
| Cell Type | Lithium Iron Phosphate Battery |
| Nominal Voltage | 51.2V |
| Voltage Range | 44.80~58.40V |
| Rated Capacity | 100Ah |
| Nominal Energy | Min: 4864Wh / Typ: 5120Wh |
| Nominal Output Power Capacity | 5.12kW |
| Communication Port | RS-485 / CAN |
| Cycle Life | ≥6000 times @ 80% DOD, 25°C |
| Recommended Scope of SOC | 10% ~ 90% (Better cycle life) |
| Mounting Type | Wall Mounting |
| Package Dimensions | 119*50.4*116.2 |
| Gross Weight | 53.9kg |
| Working Temperature Range | -20°C ~ +55°C |
